Consumables / chip

Chip

Consumables / chip

Wanguiyuan provides one-stop services covering the R&D, mold manufacturing, injection molding, bonding, and quality inspection of various chip types, including cartridge, disc, cassette, and planar formats. We deliver cost-efective chip products with strong core competitiveness.

Download Data Online Consultation

Product Advantages

Minimum channel size: 30 μm

Minimum channel size: 30 μm

Achievable aspect ratio: 1:1 to 3:1

Achievable aspect ratio: 1:1 to 3:1

Surface finish: ≤ Ra 0.2 μm

Surface finish: ≤ Ra 0.2 μm

Mold hardness: > HRC 42

Mold hardness: > HRC 42

Mold lifespan: > 500,000 cycles

Mold lifespan: > 500,000 cycles

Microfluidic Chips

Microfluidic Chips


Related products

Centrifugal / Disk Microfluidic Chip

Disk microfluidic chip (LabDisk) is driven by centrifugal force. With disc-shaped structure rotating around the spindle, fluid transfer, metering, lysis, purification, amplification and detection are sequentially controlled by adjusting rotating speed. It supports multi-analyte / multi-sample parallel testing in a single disposable closed chip, enabling sample-in answer-out workflow.

Centrifugal / Disk Microfluidic Chip

Cartridge Microfluidic Chip

rectangular, the most common format for molecular POCT, equipped with airbag/blister reagent chambers, widely used in molecular diagnostic instruments

Cartridge Microfluidic Chip

Consumables / chip

Wanguiyuan provides one-stop services covering the R&D, mold manufacturing, injection molding, bonding, and quality inspection of various chip types, including cartridge, disc, cassette, and planar formats. We deliver cost-efective chip products with strong core competitiveness.

Consumables / chip

Automated Microfluidic Assembly

Provides functions for microfluidic chips including automatic feeding, laser welding, laser cutting, UV bonding, UV curing, sterile cleaning, vacuum drying, reagent pre-loading (nL level and above), lyophilized bead dispensing and component assembly, full-process visual inspection, in-line packaging, in-line QR code labeling, and automatic unloading.

Automated Microfluidic Assembly

Auto Organoid Workstation

The system performs precise counting to ensure the number and viability of organoids seeded in each well are highly consistent, laying a solid foundation for high-quality data.

Auto Organoid Workstation
